Specification

Horizontal adjustment: operating elements front, stroke 150mm.
Height / rake adjustment: operating elements ight, in fine increments up to 65mm, rake adjustable , ±14°;
Backrest adjustment: operating elements right, adjust range 80°＋41°
Head restraint adjustment: adjust range 75mm(25mmx3)
Seat size（lengthxheightxwidth） 550x930x485mm
Seat cushion height（work state）225mm ; seat cushion width 485mm ;seat cushion depth 460mm
Backrest height 520mm; backrest width 480mm
Mounting dimension:（L/RxF/B）216×295.5mm
