Specification

Horizontal adjustment: stroke 200mm (10mmx20)
Weight adjustment: adjust range 40 ~ 130Kg
Mechanical suspension function: stroke ±30mm
Height / rake adjustment: adjust range ±60mm, rake adjustable ±12°;
Backrest adjustment: adjust range 80°＋41°
Head restraint adjustment: adjust range 75mm (25mmx3)
Three-point-belt
Seat size（length x height x width） 660mmx1100mmx500mm
Seat cushion height（work state）265mm, seat cushion width 485mm seat cushion depth 480mm
Backrest height 895mm backrest width 542mm
Connect size（L/RxF/B）216mm x 320mm（280）
